Y3E Lens

Y3EA is a three prism configuration for use with a single lamp giving superb distribution characteristics.

• Corridors
• Cashier & other service counters
• Task luminaires
• Lecture facilities
• Clinical bed-head luminaires

Y3EA is a highly specialised lens comprising a three prism configuration arranged to create a unique control panel providing an unmatched asymmetric distribution with a peak intensity between 40? and 45?.

Y3EA is designed for use with a single lamp with the option to utilize two panels for twin lamp configurations.

Y3EA possesses superb distribution characteristics with efficiency values of nearly 60%.

Acrylic material used in Y3EA meets or exceeds recognised standards.

Under normal interior conditions these lenses will perform satisfactorily for 20 years.

Y3EA is manufactured from 100% Acrylic (Polymethylmethacrylate). Flammability Rating-UL94 HB.


Y3EA is 4mm thick.

Standard Sizes
Generally used in single lamp luminaires with openings of approximately 200mm.

The diagram gives an indication of correct configuration of lamp – luminaire – Y3EA Lens.

Alternative configurations are possible providing differing angles of maximum intensity.

Please note that correct orientation and position of prisms is essential to obtain optimum performance.

Photometric Data
